If you’ve ever purchased lighting or electronics for the bathroom, garden, or other damp environment, you’ve probably seen the term “IP rating.” But what exactly does that mean? An IP rating (Ingress Protection) is an internationally recognized code that indicates how well a device is protected against dust and water. It helps you determine whether a product is suitable for certain environments, such as outdoors or in wet areas.
An IP rating consists of two digits. The first digit indicates protection against solid objects, such as dust or fingers. The second digit indicates how well the product is protected against moisture. The higher the numbers, the better the protection. Examples are IP68 or IPX2.
Heeft u vragen of deskundig advies nodig? Wij helpen u graag verder! U kunt ons bereiken via +31 (0) 88 033 0300 of door een mailtje te sturen naar info@vonkbv.com.
Aan deze pagina wordt nog verder gewerkt.
The first digit in the IP rating indicates the degree of protection the enclosure provides against solid foreign objects such as dust, accidental contact with hands, fingers, tools, wires, etc. The corresponding descriptions of the digits are explained below:
| First number: | Description of solid protection: |
| 0 (X) | No Protection |
| 1 | Protection against solid particles with a diameter of more than 50 mm |
| 2 | Bescherming tegen vaste deeltjes met een diameter van 12,5 mm of meer |
| 3 | Protection against solid particles with a diameter of 2.5 mm or more |
| 4 | Protection against solid particles with a diameter of 1 mm or more |
| 5 | Protection against dust particles |
| 6 | Dustproof; Complete protection |
The second digit in the IP rating defines the degree of protection against liquid ingress. A brief description of the corresponding digits follows.
| Second number: | Description of liquid or moisture protection: |
| 0 | No Protection |
| 1 | Protection against vertical dripping water |
| 2 | Protection against dripping water when the housing is tilted up to an angle of 15° |
| 3 | Protection against splash water up to an angle of 60° from vertical |
| 4 | Protection against splash water from all directions |
| 5 | Protection against directed low pressure water jets (6.3 mm) from any angle |
| 6 | Protection against high pressure (12.5 mm) targeted water jets from any angle |
| 7 | Protection against complete immersion to a depth of 1 m for 30 minutes |
| 8 | Protection against immersion to greater depths and higher pressures |
| 9 (K) | Protection against directed water jets at high temperature and pressure, rinsing or steam cleaning procedures |
